Muturi BLDC kwadri
Qawwa tal-Ħruġ minn 26 W sa 2070 W
Daqs tal-mutur minn 42mm sa 110mm (Nema 17 sa Nema 42)
Għażliet integrati tal-mutur servo mingħajr brushes (polz / RS485 / CANopen).
Ħafna tipi ta 'xaft differenti disponibbli
Spur gearbox, worm gearbox, gearbox planetarju disponibbli
Guangzhou Haoqing Mechanical And Electrical Equipment Co., Ltd huwa wieħed mill-manifatturi u fornituri ewlenin ta 'muturi bldc kwadri fiċ-Ċina. Merħba biex tixtri muturi bldc kwadri ta' grad-għoli magħmula fiċ-Ċina hawn mill-fabbrika tagħna. Il-prodotti kollha personalizzati huma ta 'kwalità għolja u prezz baxx.
Mutur BLDC kwadru
- Qawwa tal-Ħruġ minn 26 W sa 2070 W
- Daqs tal-mutur minn 42mm sa 110mm (Nema 17 sa Nema 42)
- Għażliet integrati tal-mutur servo mingħajr brushes (polz / RS485 / CANopen).
- Ħafna tipi ta 'xaft differenti disponibbli
- Spur gearbox, worm gearbox, gearbox planetarju disponibbli
- Għażliet ta 'Brejk / Encoder elettromanjetiċi
- Sewwieqa tal-Input AC jew DC
- Partijiet Personalizzati: Muturi, Gearboxes, Encoders, Brejkijiet, Sewwieqa Integrati
Karatteristiċi
- Ebda xkupilji - Manutenzjoni Mnaqqsa u Żieda fil-Ħajja
- Effiċjenza Għolja u Telf ta 'Enerġija Baxxa
- Torque Għoli-għall--Proporzjon tal-Piż
- Kontroll Preċiż tal-Veloċità u l-Pożizzjoni
- Operazzjoni kwieta u bla xkiel
- Firxa Wiesgħa ta 'Veloċità u Prestazzjoni Dinamika
- Ġestjoni Termali Eċċellenti Disinni Customizable u Konfigurazzjonijiet Modulari
- Metodi ta' Kontroll Multipli
- Integrazzjoni ma' Interfaces u Sensuri Diġitali
Data tal-Mutur
1:Nema17 42BLS Serje Pjazza Brushless DC Motors
|
Mudell |
Fażi |
Pollakki |
Vultaġġ Rated |
Veloċità Rated |
Torque Rated |
Kurrent Rated |
Qawwa Rated |
Tul tal-Korp |
Inerzja tar-rotor |
|
Vdc |
Rpm |
N.m |
A |
W |
mm |
g.ċm2 |
|||
|
42BLS01 |
3 |
8 |
24 |
4000 |
0.0625 |
1.8 |
26 |
41 |
24 |
|
42BLS02 |
3 |
8 |
24 |
4000 |
0.125 |
3.3 |
52.5 |
61 |
48 |
|
42BLS03 |
3 |
8 |
24 |
4000 |
0.185 |
4.8 |
77.5 |
81 |
72 |
|
42BLS04 |
3 |
8 |
24 |
4000 |
0.25 |
6.3 |
105 |
100 |
96 |
2:Nema23 57Serje BLF Round Brushless DC Motors
|
Mudell |
Fażi |
Pollakki |
Vultaġġ Rated |
Veloċità Rated |
Torque Rated |
Kurrent Rated |
Qawwa Rated |
Tul tal-Korp |
Inerzja tar-rotor |
|
Vdc |
Rpm |
N.m |
A |
W |
mm |
g.ċm2 |
|||
|
57BLF005 |
3 |
4 |
36 |
4000 |
0.055 |
1.2 |
23 |
37 |
30 |
|
57BLF01 |
3 |
4 |
36 |
4000 |
0.11 |
2.0 |
46 |
47 |
75 |
|
57BLF02 |
3 |
4 |
36 |
4000 |
0.22 |
3.6 |
92 |
67 |
119 |
|
57BLF03 |
3 |
4 |
36 |
4000 |
0.33 |
5.3 |
138 |
87 |
173 |
|
57BLF04 |
3 |
4 |
36 |
4000 |
0.44 |
6.8 |
184 |
107 |
230 |
3:Nema24 60BLS Serje Pjazza Brushless DC Motors
|
Mudell |
Fażi |
Pollakki |
Vultaġġ Rated |
Veloċità Rated |
Torque Rated |
Kurrent Rated |
Qawwa Rated |
Tul tal-Korp |
Inerzja tar-rotor |
|
Vdc |
Rpm |
N.m |
A |
W |
mm |
kg.ċm2 |
|||
|
60BLS01 |
3 |
8 |
48 |
3000 |
0.3 |
2.8 |
94 |
78 |
0.24 |
|
60BLS02 |
3 |
8 |
48 |
3000 |
0.6 |
5.2 |
188 |
99 |
0.48 |
|
60BLS03 |
3 |
8 |
48 |
3000 |
0.9 |
7.5 |
283 |
120 |
0.72 |
|
60BLS04 |
3 |
8 |
48 |
3000 |
1.2 |
9.5 |
377 |
141 |
0.96 |
4:Nema34 86BLS Serje Pjazza Brushless DC Motors
|
Mudell |
Fażi |
Pollakki |
Vultaġġ Rated |
Veloċità Rated |
Torque Rated |
Kurrent Rated |
Qawwa Rated |
Tul tal-Korp |
Inerzja tar-rotor |
|
Fażi |
Pollakki |
Vdc |
Rpm |
N.m |
A |
W |
mm |
g.ċm2 |
|
|
86BLS58 |
3 |
8 |
48 |
3000 |
0.35 |
3 |
110 |
71 |
400 |
|
86BLS71 |
3 |
8 |
48 |
3000 |
0.7 |
6.3 |
220 |
84.5 |
800 |
|
86BLS84 |
3 |
8 |
48 |
3000 |
1.05 |
9 |
330 |
98 |
1200 |
|
86BLS98 |
3 |
8 |
48 |
3000 |
1.4 |
11.5 |
440 |
111.5 |
1600 |
|
86BLS125 |
3 |
8 |
48 |
3000 |
2.1 |
18 |
660 |
138.5 |
2400 |
5:Nema42 110BLS Serje Pjazza Brushless DC Muturi
|
Mudell |
Fażi |
Pollakki |
Vultaġġ Rated |
Veloċità Rated |
Torque Rated |
Kurrent Rated |
Qawwa Rated |
Tul tal-Korp |
|
Vdc |
Rpm |
N.m |
A |
KW |
mm |
|||
|
110BLS50 |
3 |
8 |
310 |
3000 |
2.38 |
2.7 |
0.75 |
134 |
|
110BLS75 |
3 |
8 |
310 |
3000 |
3.3 |
3.7 |
1.03 |
159 |
|
110BLS100 |
3 |
8 |
310 |
3000 |
5 |
5.6 |
1.57 |
184 |
|
110BLS125 |
3 |
8 |
310 |
3000 |
6.6 |
7.5 |
2.07 |
209 |
